DIGITUS Pro 4K HDMI Extender over IP Receiver Unit Factory Sealed
You have to log in to shop/see prices.
|
|
DIGITUS Pro 4K HDMI Extender over IP Receiver Unit Factory Sealed
-
Type
Video Extender / Receiver
|
Description
Specifications
Extend the 4K HDMI Extender via CAT / IP Set with additional receiver units (DS-55123). The Extender Set (DS-55122) is a high-performance video distribution system consisting of a transceiver unit. It extends 4K HDMI signals to up to 120 m via a CAT6 network cable (point-to-point connection). In addition, you can use a network switch and the individual receiver units (DS-55123) to distribute your video content to up to 253 displays via the already existing network (IP connection). The additional integrated unidirectional IR interface allows a remote control of the input source.
- Use additional receiver units (DS-55123) and your existing network infrastructure to display your video content on up to 253 screens (IP connection)
- Extends 4K video content to up to 120 m with a CAT 6 cable (point-to-point connection)
- Signal extension (unlimited distance) via the existing local network infrastructure (IP connection)
- Supports 4K (30Hz), 3840x2160p resolution
- Supports CAT 5, CAT 5e, and CAT 6 network cables
- HDMI bandwidth: 10.2 Gbit/s (max.)
- Supports HDCP 1.4
| Modell | AV-mottagare |
| Maximal upplösning | 3840 x 2160 pixlar |
| Kabeltyper som stöds | Cat5,Cat5e,Cat6 |
| Maximal överföringshastighet avstånd | 120 m |
| Videolägen som stöds | 480i,480p,576i,576p,720p,1080i,1080p,2160p |
| Bandbredd | 10,2 Gbit/s |
| HDCP | Yes |
| Material | Metall |
| Färgdjup | 24 bit |
| 3D kompatibilitet | Yes |
| Produktens färg | Svart |
| Anslutningsteknologi | Kabel |
| RJ-45 ingångsportar | 1 |
| Antal HDMI-utgångar | 1 |
| HDMI-version | 1.4 |
| Remote (IR) ingång | 1 |
| Likströmsingång | Yes |
| Uteffekt | 2 A |
| Arbetsspänning (mottagare) | 5 V |
| Strömförbrukning (vanlig) | 4 W |
| Extern laddare | Yes |
| Temperatur vid drift | 0 - 60 ° C |
| Bredd | 107,3 mm |
| Djup | 94 mm |
| Höjd | 23,7 mm |
| Vikt | 167 g |
| Förpackningens bredd | 117 mm |
| Låddjup | 150 mm |
| Höjd | 77 mm |
| Vikt inkl. förpackning | 370 g |
| Inklusive nätadapter | Yes |
| Bruksanvisning | Yes |
| IR-mottagare ingår | Yes |
